    12 0.275-0.335 5 0.1143-0.1397 Hole Type IQI Inspection Report For Precise Measurements

    Hole type IQI inspection report

    ASTM SE 1025 Plate Penetrameters are normally used to conform with the AmericanInspection Standards.

    They are rectanqular plates, 2% in thickness of the specimenand of material radiographically similar to the specimen.

    Each plate has three holesdrilled equal in diameter to 1X, 2X, and 4X the plate penetrameter thickness.

    Theminimum thickness of Plate type penetrameter is 0.010". For Penetrameters greaterthan 0.180",

    these are supplied in disc form, the outside diameter is 4X, with 2 holes1X & 2X the thickness ofthe Penetrameter.

    The chart below gives Plate PenetrameterIdentification and thickness and a guide as to which penetrameter to use for eachmaterial thickness.

    :mm
    No.ThicknessAperture TAperture 2TAperture 4T
    RangeMeasuredRangeMeasuredRangeMeasuredRangeMeasured
    50.1143-0.13970.13950.241-0.2670.2610.495-0.5210.5191.003-1.0291.023
    70.165-0.1910.1890.241-0.2670.2630.495-0.5210.5191.003-1.0291.025
    100.241-0.2670.2470.241-0.2670.2640.495-0.5210.5191.003-1.0291.017
    120.275-0.3350.3110.275-0.3350.3290.608-0.6670.6541.238-1.3021.298
    150.349-0.4130.3920.349-0.4130.3680.730-0.7940.7621.492-1.5561.522
    170.400-0.4640.4060.400-0.4640.4110.857-0.9210.9111.746-1.8101.795
    200.476-0.5400.4840.476-0.5400.5050.984-1.0481.0192.000-2.0642.018
    250.571-0.6990.6530.571-0.6990.6461.206-1.3341.2882.476-2.6042.498
    300.698-0.8260.7690.698-0.8260.7211.460-1.5581.5142.984-3.1123.039
    350.825-0.9530.8870.825-0.9530.9071.714-1.8421.7663.492-3.6203.577
    400.952-1.0800.9720.952-1.0801.0191.968-2.0961.9874.000-4.1284.118
    451.079-1.2071.2011.079-1.2071.2012.222-2.3502.314.508-4.6264.619
    501.206-1.3341.3111.206-1.3341.3142.476-2.6042.5355.016-5.1445.106
    601.397-1.6511.5271.397-1.6511.5352.921-3.1753.0145.969-6.2236.055
    701.714-1.8421.8321.714-1.8421.8323.492-3.6203.5957.048-7.1767.110
    801.905-2.1592.0021.905-2.1591.9523.937-4.1914.0618.001-8.2558.028
    1002.413-2.6672.6532.413-2.6672.6374.953-5.2075.19710.033-10.28710.265
    1202.921-3.1753.0112.921-3.1753.0125.969-6.2236.12312.065-12.31912.301
    1403.429-3.6833.5233.429-3.6833.6126.985-7.2397.15614.097-14.35114.251
    1603.937-4.1914.0153.937-4.1914.1018.001-8.2558.15516.129-16.38316.295
    2004.826-5.3345.1354.826-5.3345.0129.906-10.41410.125
    The test results meet the requirements of ASTM E1025
