Brand Name : | HUATEC |
Model Number : | HG-6430 |
Certification : | CE |
Price : | USD380/set - USD429/set |
Payment Terms : | T/T,Paypal |
Supply Ability : | 10sets/Month |
Delivery Time : | 7-10 working days after receipt of your payment |
HG-6430 LCD Digital Display Acceleration Velocity Displacement Vibration Pen
Features:
·Used for fast failure detecting of motor, electric fan, pump, air
compressor, machine
tools and so on.
·Compact size, small weight, easy handling
·Prompt testing of vibration on the workshop machines
·For quick checking of unbalance misalignment, bearings and gears
·Guard against mechanical malfunction
·Holding tested value for 40 seconds
·Automatic switch off after 40 seconds
·HG6430 is used for acceleration, velocity and displacement testing
Technical Specifications:
Parameter | Acceleration, Velocity, Displacement |
Testing range | Acceleration:0.1m/s2-199.9m/s2(peak) Velocity: 0.1mm/s-199.9 mm/s(RMS) Displacement: 0.001mm-1.999 mm (peak-peak) |
Frequency range | Acceleration: 10Hz ~ 1kHz(LO) |
Accuracy | ±5% ± 2digits |
Display | 3 1/2 digits LCD |
Power supply | two button batteries(LR44 or SR44) |
Battery capacity | Approx. 5 hours working continuously |
Operating temperature | 0℃ ~ 40℃ |
Humidity | <85% |
Dimension | 152mm×22mm×16mm |
Configuration
NO. | Item | Quantity | |
Standard Configuration | 1 | Main unit | 1 |
2 | Screwdriver | 1 | |
3 | Batteries SR44LR44 1.5V | 2 | |
4 | Box | 1 | |
5 | Document | 1(set) |
![]() |
