    CE Steel Cast Iron Aluminum Ultrasonic Metal Thickness Tester

    Ask Lasest Price
    Brand Name : Huatec
    Model Number : TG-3500
    Certification : ISO,CE
    Payment Terms : T/T, Western Union,Paypal
    Supply Ability : 500 set per month
    Delivery Time : 3-7 working days
    • Product Details
    • Company Profile

    CE Steel Cast Iron Aluminum Ultrasonic Metal Thickness Tester

    ultrasonic thickness gauge TG-3500 measure the thickness of Steel,Cast iron,Aluminum,Red copper,Brass,Quartz glass etc.

    1.FEATURES
    * Used the exclusive Micro-computer LSI circuit and crystal time base to offer high accuracy measurement.


    * With high power of emission and broad band of receiving sensitivity,the gauge can match probes of different frequencies.That makes it easy to measure the rough surface,even cast iron.It is widely used in almost all kinds of industries.


    * Applicable to measure the thickness of many materials, e.g.Steel,Castiron,Aluminum,Redcopper,Brass,Zinc,Quartzglass,Polyethylene,PVC,Graycastiron,Nodularcastiron.


    * Bidirectional measurement,formaterials within measurement range, thickness is measurable with know velocity,Converselyvelocityismeasurable with know thickness.

    2. SPECIFICATIONS

    Display:LCD
    Range:0.75~400mm (45# steel )(Depend on Probe)
    Resolution0.1 mm / 0.01mm /0.001inch
    Accuracy:±(0.5%n+0.1)
    Sound velocity1000 ~9999 m/s
    WithBluetooth interface
    Power supply4x1.5 V AAA(UM-4) battery
    Operating condition:Temp. 0~40°C
    Humidity <80%
    Size:140x72x34mm
    Weight:about185g(notincludingbatteries)
    AccessoryCarrying case…1pc
    Operation manual…1pc
    Ultrasonic sensor…1pc
    Optional accessoriesCable & software for RS232C
