    HG-911H Bearing Vibration Portable Vibration Meter FFT Analyzer / Data Collector Usb

    Ask Lasest Price
    Brand Name : Huatec
    Model Number : HG-911H
    Certification : ISO CE GOST
    Price : USD 1350~1755 set
    Payment Terms : L/C, T/T, Western Union,Paypal
    Supply Ability : 100 sets per month
    Delivery Time : 3~7 working days
    • Product Details
    • Company Profile

    HG-911H Bearing Vibration Portable Vibration Meter FFT Analyzer / Data Collector Usb

    Portable vibration meter HG-911H Bearing Vibration FFT Analyzer / Data Collector


    HG-911H is a small sized economical vibration Spectrum analyzer & data collector. It can be used for overall vibration measurement, vibration spectrum analysis & machinery condition monitoring. Measurement of high frequency acceleration envelope makes it very effective for bearing fault detection. The data can be sent to computer for database and trending analysis.


    Features:

    • All in 1 screen, a very easy to use spectrum analyzer
    • Measurement of high frequency acceleration envelope makes it a very effective bearing fault detector
    • Download from computer database point / location ID & upload overall value to database for trending
    • Standard maintenance software MCMe2/MCMe3
    • 400 line spectrum analysis,
    • Parameter selection of Acceleration, velocity, displacement and acceleration envelope
    • USB 2.0 interfaces to computer
    • Date/Time & Battery Status Display
    • True RMS measurement

    Specification:

    Maximum measurement range / Resolution / frequency range:

    Parameter

    Maximum

    Measurement Range

    Maximum

    Resolution

    Frequency Range
    Displacement Peak-Peak value2 mm1 micron10 – 500Hz
    Velocity RMS value200mm/s0.1 mm/s10 – 1000Hz
    Acceleration Peak value180m/s20.1 m/s210 – 5000Hz
    High Frequency Acceleration Envelope20unit0.1unit5Hz-2kHz #

    # Note: Demodulated from 3kHz-10kHz

    l Accuracy:

    1.Noise Level (without vibration input): ACC<0.25 m/s2, VEL<0.5mm/s, Disp<1um
    2.Frequency response accuracy: ±5% + 2 digits
    3.Non-linearity: ±5% + 2 digits

    l Rechargeable battery powered, Automatic power off, >12 hours operation time

    l Operation temperature range: 0 - 50°C

    l Pickup: Accelerometer with extension stinger and magnetic mount

    l Storage: 200 sets of ID, acceleration, velocity, displacement, envelope & spectrum

    l Size: 196 x 101 x 45 (mm)

    l Weight: 230 gram (including battery)

    HG-911H Bearing Vibration Portable Vibration Meter FFT Analyzer / Data Collector UsbHG-911H Bearing Vibration Portable Vibration Meter FFT Analyzer / Data Collector UsbHG-911H Bearing Vibration Portable Vibration Meter FFT Analyzer / Data Collector Usb
