Explosion Proof Portable Vibration Analyzer Meter EX-6 HG908B

Ask Lasest Price
Brand Name :	HUATEC
Model Number :	HG-908B
Certification :	ISO，CE，Gost
Payment Terms :	L/C, T/T, Western Union,Paypal
Supply Ability :	100 sets per month
Delivery Time :	3-7 days

Add to Cart

Product Details
Company Profile

Explosion Proof Portable Vibration Analyzer Meter EX-6 HG908B

Explosion Proof EX-6 HG908B Portable Vibration Analyzer Meter

Features:

• Measuring vibration velocity, displacement, acceleration and high-frequency acceleration
• Small size, transducer included,battery powered, Accelerometer may be integrated or external cable connected.
• One button control both power and measurement. Very easy to use.
• 3 1/2 LCD digital display, sampling per second.
• Holding function.
• Automatic power off.
• True RMS measurement.
• Suitable for monitoring machinery vibration caused by imbalance, misalignment, gear & bearing faults and etc.

Specifications:

Amplitude Ranges:

Displacement	1—1999 m m (or 200 mil) Eq. peak-peak
Velocity	0.1—199.9 mm/s (or 20 in/s) true RMS
Acceleration	0.1—199.9 m/s2 (or 20 g) Eq. Peak
High Frequency Acceleration	0.1—199.9 m/s2 (or 20 g) Eq. Peak
Overall accuracy	±5%
Temperature range	0 - 50°C

Frequency response:

Displacement 10-1000Hz

Velocity 10-1000Hz

Acceleration 10-1000Hz (908B)

10-5000Hz (908)

High Frequency Acceleration: 1000-5000Hz ±10%

• Configuration:

HG908B: Integrated accelerometer with handheld probe

HG908: Outside accelerometer with magnetic mount & probe

• Battery: 9V 6F22/Rechargeable, 25/10 hours of continuous operation.

• Pickup: Accelerometer with handheld probe and/or magnetic mount

• Dimensions: 13×6×2.3 cm;

Weight: 200 g

• Optional Intrinsically safe version with internal accelerometer
