    XXG-2005 Portable x-ray machine for welding , nondestructive testing equipment

    Max penetration 29mm Directional radiation portable X - ray flaw detector XXG-2005 with ceramic x - ray tube


    XXG series are ceramic X-ray tube, both can be directional model and Panoramic, it is more durable than the glass tube: shake proof and long working life.

    XXG-2005 Portable x-ray machine for welding , nondestructive testing equipment

    Feature:
    ● Checking the software and hardware itself after start the machine

    ● Excellent anti-jamming performance, which can adapt for field operation without power supply, because of the motor supports

    ● Can adjust exposure parameters with keys ( easy operation.)

    ● Has the function of Delay time opening HV. Convenient for operator keep away from dangerous field

    ● Can adjust high voltage slowly for protecting X-ray generator

    ● Automatically controlling according to 1:1 working and rest operating way, the longest continuous exposure period is 5 minutes.

    ● Including complete protecting system: over KV, low mA, over mA, over temperature and optical-sound alarming

    ● Convenient for repairing and maintenance

    ● Much more Substance for structure designing, much more convenient for local operation

    ● Time can be changed for±0.3 according to the power supply net to make the exposure more precise


    Specification:

    Output voltage

    (Kv)

    Input

    (KW)

    Focus spot

    (mm)

    Beam angle

    Max penetration

    (mm)

    Weight (KG)

    Dimensions (mm)

    Generator

    Controller

    Generator

    Controller

    XXG-2005

    100-200

    2.0

    2.0X2.0

    40°+5°

    29

    22.5

    11

    280x280x650

    350x290x160


    Standard Delivery

    Directional glass X-ray tube

    1 Pcs

    Generator

    1 Set



    High voltage joins cable

    1 Pcs

    25 Meters

    Controller

    1 Set



    Power cable

    1 Pcs

    10 Meters

    Grounding cable

    1 Pcs

    5 Meters

    Accessories

    1 Set



    (Including: alarm lamp,1 Pcs; lead letter, 1 box; Film dark cassettes 5 pcs; intensifying screen 5 pcs; Wire penetrameter (IQI) 1 set; fuse1 pc)
