    Portable Eddy Current Coating Thickness Tester Gauge TG-2200CN Bluetooth / USB Data

    Ask Lasest Price
    Brand Name : HUATEC
    Model Number : TG-2200CN
    Certification : CE ISO
    Payment Terms : T/T, Western Union, L/C
    Supply Ability : 3000 pcs per month
    Delivery Time : 3 working days
    • Product Details
    • Company Profile

    Portable Eddy Current Coating Thickness Tester Gauge TG-2200CN Bluetooth / USB Data


    Portable Eddy Current Coating Thickness Tester Gauge TG-2200CN Bluetooth / USB Data


    Applications:

    The TG-2200CN measure the thickness of non-magnetic coatings on non-magnetic metals. It is used on anodizing, varnish, paint, enamel, plastic coatings, powder, etc. applied to aluminum, brass, non-magnetic stainless steel, etc.


    Features Details Accessories

    * Specially for the thickness measurement of coating on small work piece.

    * Measuring methods: eddy current (N).

    * Two measurement mode: Single and Continuous(Notice:Continuous mode is convenient to measure the coating thickness of curved objects and tiny objects.)

    * Metric/imperial system selectable.

    * Manual or automatic shut down.

    * Auto memory of calibration value, and auto recognize the substrate.

    * Operation process have buzzing reminder, while no buzzing in continuous mode.

    * Use “USB data output” and “RS-232 data output” to connect with PC.

    * Provide “Bluetooth data output” choice.

    * Separate Type can provide several type probe, measure can be more flexibility.


    Operating Principle

    Eddy Current (NF)

    Measuring Range

    0~200 um / 0~8 mil

    Resolution

    0.1 um

    Min. Radius Workpiece

    convex 2 mm / concave 4 mm

    Min. Measuring Area

    2 mm

    Min. Sample Thickness

    0.1 mm

    Accuracy

    ± 1~3%n or ± 2.5 um

    Auto Power Off


    Metric / Imperial

    Convertible

    Battery Indicator

    Low Battery Indicator

    Operating Conditions

    Temp. 0~40 °C, Humidity: 10~90 %RH

    Power Supply

    4 x 1.5 V AAA (UM-4) Battery

    Dimensions

    140 x 72 x 34 mm ( 5.5 x 2.8 x 1.3 inch )

    Weight

    215 g (Not Including Batteries)


    Standard Accessories:

    1. Main Unit

    2. Probe (NF Type)

    3. Calibration Base Set (NF Type)

    4. Calibration Foils (1 set, 4 pieces)

    5. Carrying Case

    6. Operation Manual


    Optional accessories:

    1. USB, RS-232C data cable with software
    2. Bluetooth data out put with software
